The specification of CP1E-N14DR-A
| FUNCTIONS | PARAMETERS |
| Brand Name | Omron |
| Model Number | CP1E-N14DR-A |
| Power Supply | 100 to 240 VAC |
| Inputs | 8 |
| Outputs | 6 |
| Output type | Relay |
| Program capacity | 8k steps |
| Data memory capacity | 8K words |
| Current Consumption (A) | 5V (0.17); 24V (0.07) |
Features:
New CP1E CPU Units now available.
– Lineup including CPU Units with built-in three ports: USB, RS-232C, RS-485.
– The depth of CPU Units with RS-232C connectors is reduced by 20 mm. (N30/40/60S(1))
– Easy connection with computers using commercially available USB cables.
– With E30/40/60(S), N30/40/60(S@) or NA20 CPU Units, Add I/O, Analog I/O or Temperature Inputs by Connecting Expansion Units or Expansion I/O Units.
– Input interrupts
– Complete High-speed Counter Functionality.
– Versatile pulse control for Transistor Output for N14/20/30/40/60(S@) or NA20 CPU Units.
– PWM Outputs for Transistor Output for N14/20/30/40/60(S@) or NA20 CPU Units.
